| Halogen-Free, Lead-free, No-clean solder paste |
| |
|
| Product Use: |
|
| |
|
| Environmental-friendly electronic assembly is upgrading! Following the Lead-Free transition, there a new requirement for GREEN electronic materials: Halogen-Free. Halogen elements, Mainly Br and Cl, no matter electrovalent or covalent, are used in flux as the activator. Since halogen element could effectively replace the oxygen in metaallic oxide, It has special effect on removing the surface oxide of soldered metal and enhancing the wetting ability. |
 |
| |
| Series of halogen-free solder pastes, available for all kinds of pb-free solders |
| High quality printability, clear and stable outline |
| Smooth printing is available even after 4 hours idle time |
| Good hot slump performance |
| The passing rate of first-time ICT is over than 97% |
| |
| Type |
Alloy Composition |
Powder Size |
| FLY 905-CW-3 |
Sn-3.0Ag-0.5Cu |
Type 25-45mm |
| FLY 905-CW-4 |
Type 20-38mm |
| SUPER105-3 |
Sn-1.0Ag-0.5Cu |
Type 25-45mm |
| SUPER105-4 |
Type 20-38mm |
| SUPER0307-3 |
Sn-0.3Ag-0.7Cu |
Type 25-45mm |
| SUPER0307-4 |
Type 20-38mm |
| FLY 806 |
Sn-58Bi |
Type 25-45mm |
|
| |
|
| Packing: 6KG/ Carton (0.5KG/Jar) |
| |
| - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - |
| |
|
| Halogen-Free, Lead-free cored solder paste |
| |
|
| Product Use: |
|
| |
|
| Environmental-friendly electronic assembly is upgrading! Following the Lead-Free transition, there a new requirement for GREEN electronic materials: Halogen-Free. Halogen elements, Mainly Br and Cl, no matter electrovalent or covalent, are used in flux as the activator. Since halogen element could effectively replace the oxygen in metaallic oxide, It has special effect on removing the surface oxide of soldered metal and enhancing the wetting ability. |
 |
| |
| New developed halogen-free, rosin-based flux NH88 for cored solder wire |
| Good wetting ability is available |
| Standard flux content is 2.0wt% or 3.0wt% |
| Minmum wire diameter could be 0.18mm |
| Available for all series of lead-free solder alloy, e.g., |
| Sn-3.0Ag-0.5Cu |
| Sn-3.7Cu |
| Sn-0.3Ag-0.7Cu |
| Sn-0.5Ag-0.7Cu |
| Sn-3.0Ag-0.5Cu |
| |
| Packing: 15KG/ Carton (15KG/Roll) |
